HT12 1.2 Ton Mini Excavator with Kubota Engine 10.2KW

HT12 1.2 Ton Mini Excavator with Kubota Engine 10.2KW

Place of origin Shandong China

Brand Name Hightop

Certification CE, EPA, ISO

Model Number HT12

Inquire Now

Product Description

Parameters

Product Features

Advantages

Product Description

The HT12 1.2 Ton Mini Excavator with Kubota Engine 10.2KW is engineered to deliver strong, stable, and consistent performance across a wide range of professional applications. Equipped with a reliable Kubota engine known for its longevity, low maintenance requirements, and efficient output, this compact excavator offers excellent operational reliability even in demanding working environments. The machine is CE- and ISO-certified and fully meets EPA and Euro 5 emission standards, making it suitable for global markets that prioritize safety, environmental protection, and long-term durability.

Designed for versatility, the HT12 1.2 Ton Mini Excavator with Kubota Engine 10.2KW is capable of handling an extensive list of tasks such as trenching for fertilizer lines, planting and weeding, soil tilling, and removing stubborn tree roots in orchards. Beyond agriculture, it is highly effective in municipal engineering, roadside maintenance, small-scale construction, foundation preparation, landscape improvements, and similar operational scenarios. Its compact size and smart structural layout allow the excavator to maneuver within restricted areas while maintaining powerful digging performance.

With its user-friendly operation, fuel efficiency, and low noise output, the HT12 1.2 Ton Mini Excavator with Kubota Engine 10.2KW ensures a smooth working experience for both seasoned operators and first-time users. The machine’s robust powertrain design and upgraded hydraulic system provide fast response times, strong breakout force, and consistent productivity, making it the ideal compact excavator for professionals seeking both high value and dependable performance.

Parameters

Model	HT12
Weight	1200kg
Digging bucket capacity	0.025 cmb/120kg
Bucket width	380mm
Engine	Kubota Engine D722
Bore stroke	Three cylinders,water cool
Rated power	10.2kw/2500r/min
Displacement	6.8mlr
Main pump	G5-6
Swing motor	China brand
Travelling motor	China brand USA EATON motor(optional)
Travel speed	1.5kmh
Battery	12V 60A
Main Demensions
Overall dimension( LxWxH)	2770x896x1490 mm
Wheelbase	910 mm
Total length of track	1230mm
Plattorm ground clearance	380 mm
Platform back tuming radius	784 mm
Chassis width	896 mm
Track width	180 mm
Chassls ground clearance	132 mm
Track height	320 mm
Operating Range
Max Digging depith	1650 mm
Max. Vertical dgging depth	1375 mm
Max Digging height	2610 mm
Max. Dumping height	1850 mm
Max, Digging radius on ground	2850 mm
Min. Rotation radius	1330 mm
Max. Upgrade helght of bulldozer blade	345mm
Max. Digging depth of bulozer blade	255 mm

Product Features

HT12 Mini Excavator

Advantages

Compact in form, highly adaptable to confined spaces

With a body width of just 940 millimetres, it easily passes through most doorways, gaining access to indoor spaces, greenhouses, alleys and other areas inaccessible to larger equipment. Paired with optional retractable tracks and a swing arm capable of rotating 60 degrees to either side, it offers flexible angle adjustment for precise excavation and debris clearance in confined spaces.

Power output is stable, energy-efficient and environmentally compliant

Equipped with renowned engines such as KOOP 192F or Kubota, delivering a maximum rated power of 10.2 kW, it offers ample power and stable operation. Featuring an advanced combustion system design, it achieves low fuel consumption while meeting international emission standards including Euro 5 and EPA. Certified to CE and ISO standards, it produces minimal noise pollution, making it suitable for diverse environmental requirements both domestically and internationally.

The workmanship is solid and the durability is outstanding

The vehicle's structural components undergo multiple processing stages including shot blasting, acid washing, phosphating and spraying, ensuring superior paint adhesion that resists rusting and fading. Hydraulic pipes are sourced exclusively from Continental AG in Germany, while other hydraulic components and tracks are supplied by renowned domestic manufacturers, guaranteeing quality and extending service life under demanding operating conditions.

Safe and worry-free, with low maintenance costs

The standard-fit bulldozer blade both assists operations and protects the machine body, enhancing operational safety. The hydraulic oil tank capacity reaches 25 litres, 6 litres larger than comparable products, extending continuous working time in hot weather. The machine features an open-access body cover design with clearly laid-out piping. Core components carry a 1.5-year warranty, while interchangeable parts ensure easy procurement, facilitating both routine inspections and subsequent maintenance.
