SKID STEER LOADER

HTSL390 Mini Skid Steer Loader with Max Working Height 2398mm

Place of origin Shandong China
Brand Name Hightop
Certification CE, EPA, ISO
Model Number HTSL390

Product Description

The Hightop HTSL390 Mini Skid Steer Loader is a wheeled skid steer loader specifically engineered for small-to-medium-scale precision operations. Built around the principles of compact agility, multi-functional versatility, and user-friendly operation, this machine delivers superior performance across a wide range of light-duty applications. The HTSL390 Mini Skid Steer Loader is designed to handle loading, unloading, material handling, and short-distance transport with ease, providing a practical solution for efficiency-focused operations.

Engineered for modern construction, agricultural, and industrial needs, the HTSL390 Mini Skid Steer Loader ensures stable and reliable performance under various working conditions. Its compact design allows operators to manoeuvre in tight spaces without sacrificing productivity, while its robust build ensures durability for long-term usage. The loader’s versatility is enhanced by an adaptable hydraulic system and heavy-duty components that provide smooth operation and extended service life. This loader is particularly suitable for small contractors, agricultural enterprises, warehouse facilities, and light industrial operations, where efficiency and manoeuvrability are critical.

Supporting bespoke customization, the HTSL390 Mini Skid Steer Loader can be adapted to meet specific operational requirements, enabling cross-border supply and a wide variety of attachments. This adaptability allows operators to reduce equipment costs by consolidating multiple functions into a single machine. Whether handling materials, performing ground preparation, or supporting minor demolition work, the HTSL390 Mini Skid Steer Loader stands out as a compact, high-performing solution.

Parameters

Max working height

2398mm

Max pin height

1815 mm

Max Dumping height

1430mm

Max Dumping distance

366mm

Max Dumping Angle

23°

Total height

2020mm

Ground clearance

185 mm

Wheel base

815mm

Overall length without bucket

2030mm

Total width

1050mm

Bucket width

1050mm

Total length with bucket

2481mm

Engine Model

RATO R420

Rated Power

10Kw/3600rpm

Rotating speed

3600 rpm

Noise Level

≤95 Db

Pressure

0-17 Mpa

Flow rate

0-18L

Operating Load

250KG

Bucket Capacity

0.13m³

Max Lifting Force

200 Kg

Operating Weight

0-4.5Km/h

Total height

850kg

Fuel tank

1.7L

Hydraulic tank

23L

Product Features

 HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader HTSL390 Mini Skid Steer Loader

Advantages

Compact and flexible
Weighing just 850kg and measuring 1050mm in width, its slim profile allows effortless manoeuvring through confined spaces such as factory buildings, residential areas and greenhouses. This addresses blind spots in large equipment operations and adapts to a variety of restricted environments.
Reliable power
Equipped with the proven RATO R420 engine, delivering a stable rated power output of 10 kW with outstanding fuel efficiency; Wear-resistant tyres provide superior traction, adapting to complex terrain such as gravel and muddy conditions to ensure reliable operational availability.
Easy to operate
The responsive hydraulic system enhances operational precision, while the ergonomically designed control panel offers a straightforward and intuitive interface. Novices can swiftly familiarise themselves with the controls, thereby reducing training and labour costs.
Wide range of applications
Supports multi-colour customisation to meet individual requirements, complies with operational standards across multiple overseas regions, and serves as a cross-border model suitable for diverse scenarios including domestic and international engineering projects, agriculture and forestry, and industrial sites.
