Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale

Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale

Place of origin Shandong China

Brand Name Hightop

Certification CE, EPA, ISO

Model Number HT30

Inquire Now

Product Description

Video

Applications

Parameters

Features

Advantages

Product Description

The Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale is a compact yet powerful 3-ton hydraulic crawler excavator engineered for high performance, cost-effective operation, and multi-scenario versatility. Built with a reinforced structure and an efficient hydraulic system, this model delivers the strength required for small to medium-scale earthmoving tasks while maintaining exceptional mobility in tight or restricted spaces. With its compact chassis and optimized weight distribution, it is well-suited for municipal projects, agricultural production, landscaping work, and construction jobs that require precision and reliability.

Powered by a high-quality imported engine, the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale ensures strong torque output, fuel efficiency, and stable long-term performance. Its design focuses on reducing energy consumption while maintaining operational stability, making it an excellent choice for contractors, small construction teams, and individual operators seeking fast return on investment. The HT30’s digging force, smooth hydraulic control, and multi-attachment compatibility allow the operator to complete trenching, grading, breaking, drilling, and leveling tasks with ease.

With a flexible swing boom, telescopic chassis, and powerful hydraulic system, the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale offers the right balance of size, power, and maneuverability. This combination allows it to perform efficiently even in narrow alleys, residential zones, greenhouses, orchards, and interior renovation sites. Its sturdy crawler design reduces ground pressure, enabling stable performance on muddy fields, soft soil, and uneven terrain, while ensuring minimal damage to grasslands and crops. For those seeking a dependable and economical excavator capable of handling diverse working environments, the HT30 stands as an ideal solution.

Video

Applications

Urban Road Maintenance
The Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale plays a vital role in municipal road maintenance. Its compact frame and zero-interference tail design allow it to work along sidewalks, inside narrow community lanes, and beside traffic without occupying main road space. It excels in breaking old pavement, excavating utility trenches for water, electricity, and fiber-optic cables, and performing precise digging around buried municipal pipelines. Its agility significantly reduces construction time and minimizes urban disruption.

Farmland Consolidation
In agricultural environments, the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale supports various field preparation tasks including irrigation channel excavation, land leveling, ridge formation, and clearing stones or stubborn roots. Its track system prevents soil compaction and maintains ground structure, making it ideal for long-term agricultural use. With attachments such as narrow buckets and rippers, it enhances productivity in fruit orchards, vegetable farms, and large greenhouses.

Nursery Stock Cultivation
For landscaping companies and tree nurseries, this excavator’s auger and backfill bucket facilitate efficient tree planting, transplanting, and root excavation. The Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale ensures minimal damage to surrounding soil and vegetation, making it suitable for parks, scenic areas, residential landscaping projects, and commercial gardens.

Mining Support
In small-scale mining operations, the compact size of the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale allows it to maneuver inside narrow tunnels. It is capable of clearing loose materials, loading ore, and carrying out short-distance transfer tasks. The rugged structure withstands demanding environments, delivering reliable operation even in challenging underground conditions.

Parameters

Model	HT30
Bucket capacity	0.07m
Operation Weight	3000kg
Machine Width	1300/1500mm
Maximum digging force	800 kg
Max. digging force	19.5KN
Swing speed	9.5rpm
Walking speed	2.6\4.5kw\h
Fuel tank capacity	26L
Maximum flow	1.216L\cc
Fixed work stress	20.6MPa
Operation method	Hydraulic pilot control
Track width	250mm
Overall size	38501300\15002380mm
Minimum ground clearance	230mm
Engine model	Kubota1105
Rated power	14KW\2400rpm
Engine form	Water-cooled inline three -cylinder
Hydraulic pump	Piston Pump
Travel motor	Lectra
Rotary motor	Eaton
Maximum excavation height	3980mm
Maximum loading and unloading height	2610mm
Maximum excavation depth	2430mm
Maximum excavation range	4136mm
Maximum excavation area on the ground	4100mm
Minimum turning radius of tail	750mm
Working device turning radius	1850mm

Features

1. High-Power Kubota Engine
Equipped with a reliable, fuel-efficient Kubota engine imported from Japan, the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale delivers strong power while maintaining low fuel consumption. The engine features low noise, stable performance, and worldwide after-sales service coverage, making it suitable for long-term, continuous operation.

2. Fully Hydraulic System
The advanced hydraulic system ensures smooth, precise, and responsive control. Whether performing trenching, grading, or breaking, the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale maintains peak efficiency with balanced hydraulic flow and excellent operational stability.

3. Telescopic Lower Frame
The excavator is equipped with a telescopic chassis that adjusts from 980mm during transport to up to 1300mm during operation. This provides increased stability for heavy-duty tasks while allowing the machine to enter narrow job sites with ease.

4. Swing Boom for Narrow Spaces
The swing boom allows operators to work along walls, corners, and other restricted areas without repositioning the entire machine. This enhances efficiency and safety during excavation in tight environments.

5. Optional Variable Dozer Blade and Boom Deflection
The Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale supports optional variable dozers and boom deflection systems that offer improved grading, leveling, and trench backfilling capability.

6. Modular Driver Shed Structure
The detachable driver shed allows quick disassembly, easy transport, and convenient customization. Operators can choose from canopy or cabin configurations depending on regional climate and working conditions.

7. Wide Attachment Compatibility
Compatible with a broad range of attachments including breakers, augers, grapples, narrow buckets, tilt buckets, and hitch systems. This versatility makes the Hydraulic Crawler Machine Excavator HT30 Mini Excavator for Sale capable of handling multiple tasks across construction, agriculture, landscaping, and municipal maintenance.

Advantages

Strong power

Optional engines from renowned brands such as Kubota comply with environmental emission standards, with rated speeds tailored to meet diverse industry requirements. Featuring an automatic idle function, the engine automatically transitions to idle mode four seconds after the control lever ceases movement, effectively conserving fuel. Delivering stable power output with economical energy consumption, it effortlessly handles heavy-duty operations.

Flexible and practical

The machine features a compact overall structure, incorporating a boom swing function and an optimised working attachment design to reinforce the swing frame and extend service life. Certain models are equipped with a telescopic frame, enabling smooth operation in confined spaces such as narrow aisles and orchards, as well as complex terrains, demonstrating exceptional adaptability.

Maintenance is straightforward

The chassis features a well-designed structure with core components selected from premium products, resulting in low failure rates and partial warranty coverage. Certain parts employ a modular design for straightforward disassembly, enabling subsequent inspections and replacements without complex dismantling. This significantly reduces downtime for maintenance and associated costs.

Driving and passenger safety

Featuring a fully enclosed cab with an integrated steel structure design for enhanced safety and reliability. The interior space is maximised within its class, complemented by climate control, adjustable seating and low-noise engineering. It offers unobstructed visibility and an ergonomically designed operating layout, effectively reducing fatigue during extended working hours.
